A64-OLinuXino is a single-board computer running Linux & Android. The design based on a 64-bit ARM CPU and includes 1 or 2 GB DDR3 RAM, 4 GB flash memory, microSD card socket, WiFi & BLE4.0, Ethernet, HDMI & audio output.

ANAVI Flex is an open source Raspberry Pi HAT for IoT prototyping and home automation applications. It has infrared receiver and transmitter, relay, buzzer, button, RGB LED and UART pins for debugging. The board also supports 1602 LCD display module and up to 5 I2C sensors.

ANAVI Light Controller is a certified open source hardware WiFi device for controlling a 12 V RGB LED strip. It also supports I2C sensor modules for light, temperature, humidity, and gesture recognition.

ANAVI Infrared pHAT is an add-on board that converts Raspberry Pi in a powerful remote control. It features two IR transmitters, IR receiver, three slots for I2C sensor modules, UART pins for debugging and EEPROM with board manufacturer information.

ANAVI Light pHAT is a Raspberry Pi add-on board for controlling 12V RGB LED strip. Furthermore, it has three slots for I2C sensor modules, slot for PIR motion sensor, UART pins for debugging and EEPROM with board manufacturer information.

ANAVI Flex HAT

A general purpose motor controller designed with kicad around the ATmega328 micro controller and L298P motor driver. It can drive four motors with various input options.

Axiom is a high power, high performance 100kW+ motor controller based upon the VESC platform for compatibility with firmware and GUI. It is designed for driving 650V 600A IGBTs and comes with many safety features.

A 20 keys gamer mechanical keyboard with Raspberry Pi Pico. There are two PCBs, one for the keyboard (Main-board) and another for the panel. The design of the boards and the source code of the firmware are open and free to use.

An open source "ethernet – to – 6lowpan" gateway intended for use for some LED lighting control. It is four layer single load board with DRAM running with a linux kernel.

It’s an I/O breakout board capable of switching 32 onboard latching relays and optionally 32 momentary/latching relays using addon boards switching up to 60A AC/DC 0-400V per circuit.

The CIAA Project is an open hardware and software project started to lever the argentinean industrial environment. The CIAA-ACC is a 12 layer PCB design for High Performance Computing. It has a Xilinx Zynq-7000 SoC with an ARM 2x Cortex A9 CPU and a Kintex-7 FPGA. The form factor is the expandable PCIe-104. Peripherals: 1GB DDR3 memory, Quad SPI Flash, Gbit Ethernet, Micro SDHC, USB 2.0, dual role HDMI, PCIe 1x.

The EDU-CIAA-NXP was created specifically to be used in education, as an introductory board for the CIAA-NXP (also cheaper). It has the same processor as the CIAA-NXP, an ARM Cortex-M4F/Cortex-M0 32-bit dual core, push buttons, several LEDs, ADC and DAC, many digital inputs and outputs, and is powered via USB.

The CIAA-FSL is a four layer PCB designed to be used for industrial applications, and includes high quality terminals, beside of several protections and safety considerations. It has a 32-bit processor K60 Kinetis (ARM Cortex-M4) with several communication ports, including USB OTG, Ethernet, RS485, RS232, CAN, SPI, I2C, SD, A/D, D/A and support for connection of LCD display and GPIO input/output.

The CIAA-NXP was designed to be used for industrial applications, and includes high quality terminals, beside of several protections and safety considerations. It has a 32-bit dual-core processor (ARM Cortex-M4F/M0 @204MHz) with several communication ports, including USB, Ethernet, RS485, RS232, CAN, SPI, I2C, and support for connection of LCD display and GPIO input/output.

Aimed at small footprint projects and also with PCI Express interface. It has a dual core 32-bit ARM Cortex M4F/M0+ @100 MHz CPU, with USB, PCI Express, UART, SPI, I2C, PWM and GPIOs.

The Crazyflie 1.0 is an open flying development platform. It is a versatile platform that includes a powerful Cortex-M4 MCU, 2.4GHz low latency radio and bluetooth low energy. It also has an expansion port which allows to easily add extra hardware.

CSEduino is the answer to a very low cost DIY Arduino like board. This version has a 2-layer pcb created with kicad.

Driverino-Shield is a simple, low power, controller for BLDC sensored motors. The project target was to create an Arduino shield capable of driving a PM BLDC motor rated about 50-100W. The board is fitted with TI MCT8316Z BLDC driver.

GH60 is a custom programmable mechanical keyboard designed for the geekhack community.

Glasgow is a tool for exploring digital interfaces, aimed at embedded developers, reverse engineers, digital archivists, electronics hobbyists, and everyone else who wants to communicate to a wide selection of digital devices with high reliability and minimum hassle.

HackRF One from Great Scott Gadgets is a Software Defined Radio peripheral capable of transmission or reception of radio signals from 1 MHz to 6 GHz. Designed to enable test and development of modern and next generation radio technologies, HackRF One is an open source hardware platform that can be used as a USB peripheral or programmed for stand-alone operation.

HADES FCS is an open-source flight control system for unmanned aerial vehicles (UAVs) designed completely from scratch. This includes the hardware (custom flight-control PCBs), STM32 firmware (using FreeRTOS), Kalman filtering for state estimation, control algorithms, base station, communication protocol, flight simulator, signal processing, and much, much more.

The JEMTech-ILDA-Node is a 16 bit 6 channel DAC for ILDA up to 400kpps.

JuicyBoard from plugg.ee Labs is an open source modular robotics platform that can be used to build custom 3D printers, CNC machines and more.

The Librem 5 Dev Kit is a smartphone developer kit that is used by software developers to create apps and other software for the final Librem 5 GNU/Linux smartphone. The baseboard design uses an i.MX 8M System-On-Module (SOM), a SIMCom SIM7100A/E baseband modem mPCIe module, and a RedPine RS9116 WiFi+BT M.2 module. It includes a 720x1440 capacitive touch LCD, a dual-role capable USB-C port, a Mini-HDMI port, an RJ45 ethernet port, a 3.5mm headset audio jack, a microSD slot, a 3FF micro-SIM card slot, a 2FF smartcard slot, a GSM/3G/LTE WWAN SMD antenna, a GNSS/GPS module and SMD antenna, two WLAN SMD antennas including one for diversity, a 5MP camera, an earpiece speaker, a microphone, a 9-axis IMU, an ambient light+proximity sensor, a haptic motor, a user-controllable indication LED, an 18650 li-ion battery holder for use with an on-board charge controller, and kill switches for WWAN, WiFi+BT, & camera+mic.

The device is based on the Atmel attiny85 device and use V-USB software based solution to have USB communications.

The Micropendous boards were Development Boards for Atmel’s USB AVR Microcontrollers with a Free and Open Source Software (FOSS) hardware, firmware, and software development platform. They were designed for USB peripheral and hosting development.

The MNT Reform is a modular laptop launched in 2020 featuring 7 open hardware PCBs made with KiCAD: motherboard (SoM carrier for Boundary Devices Nitrogen8M_SOM), mechanical keyboard, OLED, optical trackball, trackball sensor, trackpad, battery pack. STEP files for the CNC milled case and STL files for the 3D-printable parts are available as well. The goals of the project are to increase ownership, transparency, repairability and privacy of mobile computers.

This adaptor has multiple overlapping footprints for any occasion: up to 28 pin SOIC/SO (1.27mm pitch), up to 28-pin SSOP/TSSOP (0.65mm pitch), up to four SOT23, up to three SC70, one MSOP-10 (0.5mm pitch), one SOT223, and one SOT-143. All in a 0.8" wide DIP board. The header pins are staggered to allow press-fitting them while soldering.

NUCLEO2USB is the USBFS shield for the NUCLEO-64© compatible development boards. It can be configured as 1xDEVFS with speed override (F103/F303), 1xOTGFS, 2xOTGFS.

NUCO-V is a NUCLEO-64© compatible development board for the STM32F7 and STM32H7 series with integrated Black Magic Probe

Open Smartwatch is a completely open (ECAD/MCAD and software) smart watch. The goal is to build an open source smartwatch, with gps tracking and maps. Features include: ESP32, GPS, Time, MEMS sensors, Li-ion battery, USB serial and microSD card storage.

The Opsis is a powerful FPGA-based open source video platform for videographers and visual artists and designed to give the user complete control over high-speed video, enabling everything from real-time conference capturing solutions, to experimental visual art and even general FPGA-based video research.

QUBIK-1 and QUBIK-2 are 2 PocketQube satellites designed, developed and integrated by Libre Space Foundation. They were expected to be short-lived and were tasked to perform Launch and Early Operations Phase (LEOP) Satellite Identification and Tracking experiments.

The rusEFI project is an attempt to build an open source automotive injection Engine Control Unit (ECU) based on STM32. Hardware and software is available.

This development board features Xilinx XC6SLX series FPGA with FTDI’s FT2232H Dual-Channel USB device. The high speed USB 2.0 interface provides fast and easy configuration download to the on-board SPI flash. No programmer or special downloader cable is needed to download the bit stream to the board.

ScopeFun in an open source, all-in-one instrumentation platform. It includes an oscilloscope, arbitrary waveform generator, spectrum analyzer, logic analyzer, and digital pattern generator.

SPACEDOS dosimeters are open-source semiconductor detector based ionizing radiation spectrometers and dosimeters. They have already successfully participated in several space missions. SPACEDOS02 measures, for a period of a regular crew change lasting several months, aboard the International Space Station (ISS). SPACEDOS01 dosimeter has been modified for mounting inside CubeSats and was sent to Earth’s orbit as a part of the SOCRAT-R satellite.

The TERES I is a Do-It-Yourself Open Source Hardware and Software Laptop with ARM64 and x86 processors including MCAD files.

An open source all-in-one Arduino compatible reflow controller powered by ATtiny1634R.

Tokay Lite can be used as standalone devkit to aid developers with a convinient tool or be embedded in the bigger system to augument it with the vision and image processing data.

Another nixie clock joining the internet of things. Using IN14 nixie tubes, an ESP12e or alternatively a DS3231 RTC.

Ubertooth One is an open source 2.4 GHz wireless development platform suitable for Bluetooth experimentation.

MF/HF Upconverter for Receivers

The compact USB powered device provides a platform for developing and running a variety of applications.

The compact USB powered device provides a platform for developing and running a variety of applications.

VB-IoT1 aims at providing a compact all-in-one solution. Due to popularity and support of open source community (software and hardware), we equipped our board with a high speed ARM-core, SIM900 (or SIM800F) and Atmega processor. The board can be used as a Linux embedded platform with GSM connection, an Arduino board with SIM900 (or SIM800F) shield, a standalone GSM shield, a full scale Android board. Additionally it has the LCD connectors, and touch screen support.

In other words, this is a brushless DC motor controller, which is very configurable.

VESC controller is a 3 phase motor controller. The board measures voltages, currents, temperatures and user inputs and acts as the brain of a high power electric drivetrain. Fully opensource and compatible with VESC project firmware and GUI.

VirtualSense is an IEEE 802.15.4-compliant wireless sensor module running a Java-compatible 32 bit VM.
